5962-8771802EA Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-CDIP
- Description: ANALOG MUX DUAL 4:1 (MUX24BQ)
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
5962-8771802EA Specifications:
- MfrPart.: 5962-8771802EA
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: ANALOG MUX DUAL 4:1 (MUX24BQ)
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Bulk
- Series: -
- PartStatus: Active
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 400Ohm
- Channel-to-ChannelMatching(ΔRon): 80Ohm
- Voltage-SupplySingle(V+): ±15V
- Voltage-SupplyDual(V±): ±15V
- SwitchTime(TonToff)(Max): 2µs, 600ns
- -3dbBandwidth: -
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 2.5pF, 7pF
- Current-Leakage(IS(off))(Max): 1nA
- Crosstalk: -70dB @ 500kHz
- OperatingTemperature: -55°C ~ 125°C
- MountingType: Through Hole
- Package/Case: 16-CDIP
- 5962-8771802EA Analog Devices (ADI), ANALOG MUX DUAL 4:1 (MUX24BQ), Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
5962-8771802EA, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
