AD561KN Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Data Acquisition - Digital to Analog Converters (DAC) Package/Case: 16-DIP (0.300, 7.62mm)
- Description: 10-BIT MONOLITHIC D/A CONVERTER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
AD561KN Specifications:
- MfrPart.: AD561KN
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: 10-BIT MONOLITHIC D/A CONVERTER
- Product Category: Integrated Circuits (ICs)~Data Acquisition - Digital to Analog Converters (DAC)
- Package: Tube
- Series: AD561
- PartStatus: Obsolete
- NumberofBits: 10
- NumberofD/AConverters: 1
- SettlingTime: 250µs (Typ)
- OutputType: Current - Unbuffered
- DifferentialOutput: No
- DataInterface: Parallel
- ReferenceType: Internal
- Voltage-SupplyAnalog: 4.5V, -10.8V ~ ±16.5V
- Voltage-SupplyDigital: 4.5V, -10.8V ~ ±16.5V
- INL/DNL(LSB): ±0.5 (Max), ±1 (Max)
- Architecture: R-2R
- OperatingTemperature: -55°C ~ 125°C
- Package/Case: 16-DIP (0.300, 7.62mm)
- AD561KN Analog Devices (ADI), 10-BIT MONOLITHIC D/A CONVERTER, Integrated Circuits (ICs)~Data Acquisition - Digital to Analog Converters (DAC)
AD561KN, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
