AD7506SD Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 28-CDIP (0.605, 15.37mm)
- Description: MULTIPLEXERS/SWITCHES,16 CHANNEL
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
AD7506SD Specifications:
- MfrPart.: AD7506SD
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: MULTIPLEXERS/SWITCHES,16 CHANNEL
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Bulk
- Series: -
- PartStatus: Active
- SwitchCircuit: -
- Multiplexer/DemultiplexerCircuit: 16:1
- NumberofCircuits: 1
- On-StateResistance(Max): 450Ohm
- Channel-to-ChannelMatching(ΔRon): 18Ohm (Typ)
- Voltage-SupplySingle(V+): ±15V
- Voltage-SupplyDual(V±): ±15V
- SwitchTime(TonToff)(Max): 1.5µs, 1µs
- -3dbBandwidth: -
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 5pF, 40pF
- Current-Leakage(IS(off))(Max): 50nA
- Crosstalk: -
- OperatingTemperature: -
- MountingType: Through Hole
- Package/Case: 28-CDIP (0.605, 15.37mm)
- AD7506SD Analog Devices (ADI), MULTIPLEXERS/SWITCHES,16 CHANNEL, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
AD7506SD, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
