AD7507KN ADI DIFFERENTIAL MUX,8 CHANNEL
AD7507KN Images
AD7507KN Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 28-DIP (0.600, 15.24mm)
  • Description: DIFFERENTIAL MUX,8 CHANNEL
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
AD7507KN Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
AD7507KN Specifications:
  • MfrPart.: AD7507KN
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: DIFFERENTIAL MUX,8 CHANNEL
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Bulk
  • Series: -
  • PartStatus: Active
  • SwitchCircuit: SP4T
  • Multiplexer/DemultiplexerCircuit: 8:1
  • NumberofCircuits: 2
  • On-StateResistance(Max): 450Ohm
  • Channel-to-ChannelMatching(ΔRon): 18Ohm
  • Voltage-SupplySingle(V+): ±15V
  • Voltage-SupplyDual(V±): ±15V
  • SwitchTime(TonToff)(Max): 1.5µs, 1µs
  • -3dbBandwidth: -
  • ChargeInjection: 2pC
  • ChannelCapacitance(CS(off)CD(off)): 5pF, 20pF
  • Current-Leakage(IS(off))(Max): 5nA
  • Crosstalk: -
  • OperatingTemperature: 0°C ~ 70°C
  • MountingType: Through Hole
  • Package/Case: 28-DIP (0.600, 15.24mm)
  • AD7507KN Analog Devices (ADI), DIFFERENTIAL MUX,8 CHANNEL, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
AD7507KN, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
