ADG1209YCPZ Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-VQFN Exposed Pad, CSP
- Description: IC MULTIPLEXER DUAL 4X1 16LFCSP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG1209YCPZ Specifications:
- MfrPart.: ADG1209YCPZ-REEL7
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: IC MULTIPLEXER DUAL 4X1 16LFCSP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 200Ohm
- Channel-to-ChannelMatching(ΔRon): 3.5Ohm
- Voltage-SupplySingle(V+): 5V ~ 16.5V
- Voltage-SupplyDual(V±): ±5V ~ 16.5V
- SwitchTime(TonToff)(Max): 95ns, 100ns
- -3dbBandwidth: 550MHz
- ChargeInjection: 0.4pC
- ChannelCapacitance(CS(off)CD(off)): 1.5pF, 4.5pF
- Current-Leakage(IS(off))(Max): 100pA
- Crosstalk: -85dB @ 1MHz
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-VQFN Exposed Pad, CSP
- ADG1209YCPZ Analog Devices (ADI), IC MULTIPLEXER DUAL 4X1 16LFCSP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG1209YCPZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
