ADG1413YRUZ ADI IC SWITCH QUAD SPST 16TSSOP
ADG1413YRUZ Images
ADG1413YRUZ Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-TSSOP (0.173, 4.40mm Width)
  • Description: IC SWITCH QUAD SPST 16TSSOP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADG1413YRUZ Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADG1413YRUZ Specifications:
  • MfrPart.: ADG1413YRUZ-REEL7
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: IC SWITCH QUAD SPST 16TSSOP
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • PartStatus: Active
  • SwitchCircuit: SPST - NO/NC
  • Multiplexer/DemultiplexerCircuit: 1:1
  • NumberofCircuits: 4
  • On-StateResistance(Max): 1.8Ohm
  • Channel-to-ChannelMatching(ΔRon): 100mOhm
  • Voltage-SupplySingle(V+): 5V ~ 16.5V
  • Voltage-SupplyDual(V±): ±4.5V ~ 16.5V
  • SwitchTime(TonToff)(Max): 150ns, 120ns
  • -3dbBandwidth: 170MHz
  • ChargeInjection: -20pC
  • ChannelCapacitance(CS(off)CD(off)): 23pF, 23pF
  • Current-Leakage(IS(off))(Max): 550pA
  • Crosstalk: -100dB @ 1MHz
  • OperatingTemperature: -40°C ~ 125°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 16-TSSOP (0.173, 4.40mm Width)
  • ADG1413YRUZ Analog Devices (ADI), IC SWITCH QUAD SPST 16TSSOP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG1413YRUZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
