ADG1423BCPZ Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 10-VFDFN Exposed Pad, CSP
- Description: SPST, 1 CHANNEL, CMOS, PDSO10
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG1423BCPZ Specifications:
- MfrPart.: ADG1423BCPZ-REEL7
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: SPST, 1 CHANNEL, CMOS, PDSO10
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Bulk
- Series: -
- PartStatus: Active
- SwitchCircuit: SPST - NO/NC
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 2
- On-StateResistance(Max): 2.4Ohm
- Channel-to-ChannelMatching(ΔRon): 20mOhm
- Voltage-SupplySingle(V+): 5V ~ 16.5V
- Voltage-SupplyDual(V±): ±4.5V ~ 16.5V
- SwitchTime(TonToff)(Max): 145ns, 145ns
- -3dbBandwidth: 180MHz
- ChargeInjection: -5pC
- ChannelCapacitance(CS(off)CD(off)): 18pF, 22pF
- Current-Leakage(IS(off))(Max): 500pA
- Crosstalk: -74dB @ 1MHz
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 10-VFDFN Exposed Pad, CSP
- ADG1423BCPZ Analog Devices (ADI), SPST, 1 CHANNEL, CMOS, PDSO10, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG1423BCPZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
