ADG1634BCPZ Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 20-WFQFN Exposed Pad, CSP
- Description: IC SWITCH QUAD SPDT 20LFCSP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG1634BCPZ Specifications:
- MfrPart.: ADG1634BCPZ-REEL7
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: IC SWITCH QUAD SPDT 20LFCSP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- SwitchCircuit: SPDT
- Multiplexer/DemultiplexerCircuit: 2:1
- NumberofCircuits: 4
- On-StateResistance(Max): 4.5Ohm
- Channel-to-ChannelMatching(ΔRon): 120mOhm
- Voltage-SupplySingle(V+): 3.3V ~ 16V
- Voltage-SupplyDual(V±): ±3.3V ~ 8V
- SwitchTime(TonToff)(Max): 38ns, 152ns
- -3dbBandwidth: 109MHz
- ChargeInjection: -12.4pC
- ChannelCapacitance(CS(off)CD(off)): 19pF, 32pF
- Current-Leakage(IS(off))(Max): 100pA
- Crosstalk: -64dB @ 1MHz
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 20-WFQFN Exposed Pad, CSP
- ADG1634BCPZ Analog Devices (ADI), IC SWITCH QUAD SPDT 20LFCSP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG1634BCPZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
