ADG202ABQ ADI QUAD SPST SWITCH
ADG202ABQ Images
ADG202ABQ Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-CDIP (0.300, 7.62mm)
  • Description: QUAD SPST SWITCH
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADG202ABQ Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADG202ABQ Specifications:
  • MfrPart.: ADG202ABQ
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: QUAD SPST SWITCH
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • SwitchCircuit: SPST - NO
  • Multiplexer/DemultiplexerCircuit: 1:1
  • NumberofCircuits: 4
  • On-StateResistance(Max): 90Ohm
  • Channel-to-ChannelMatching(ΔRon): 4.5Ohm
  • Voltage-SupplySingle(V+): 10V ~ 15V
  • Voltage-SupplyDual(V±): ±10V ~ 15V
  • SwitchTime(TonToff)(Max): 300ns, 250ns
  • -3dbBandwidth: -
  • ChargeInjection: 20pC
  • ChannelCapacitance(CS(off)CD(off)): 5pF
  • Current-Leakage(IS(off))(Max): 2nA
  • Crosstalk: -80dB @ 100kHz
  • OperatingTemperature: -40°C ~ 85°C (TA)
  • MountingType: Through Hole
  • Package/Case: 16-CDIP (0.300, 7.62mm)
  • ADG202ABQ Analog Devices (ADI), QUAD SPST SWITCH, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG202ABQ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
