ADG211AKN ADI QUAD SPST SWITCH
ADG211AKN Images
ADG211AKN Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-DIP (0.300, 7.62mm)
  • Description: QUAD SPST SWITCH
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADG211AKN Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADG211AKN Specifications:
  • MfrPart.: ADG211AKN
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: QUAD SPST SWITCH
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • SwitchCircuit: SPST - NC
  • Multiplexer/DemultiplexerCircuit: 1:1
  • NumberofCircuits: 4
  • On-StateResistance(Max): 115Ohm
  • Channel-to-ChannelMatching(ΔRon): 5.75Ohm
  • Voltage-SupplySingle(V+): 15V
  • Voltage-SupplyDual(V±): ±15V
  • SwitchTime(TonToff)(Max): 600ns, 450ns
  • -3dbBandwidth: -
  • ChargeInjection: 20pC
  • ChannelCapacitance(CS(off)CD(off)): 5pF, 5pF
  • Current-Leakage(IS(off))(Max): 5nA
  • Crosstalk: -80dB @ 100kHz
  • OperatingTemperature: -40°C ~ 85°C (TA)
  • MountingType: Through Hole
  • Package/Case: 16-DIP (0.300, 7.62mm)
  • ADG211AKN Analog Devices (ADI), QUAD SPST SWITCH, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG211AKN, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
