ADG412BR ADI PRECISION QUAD SPST SWITCH
ADG412BR Images
ADG412BR Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-SOIC (0.154, 3.90mm Width)
  • Description: PRECISION QUAD SPST SWITCH
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADG412BR Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADG412BR Specifications:
  • MfrPart.: ADG412BR-REEL7
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: PRECISION QUAD SPST SWITCH
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Bulk
  • Series: -
  • PartStatus: Obsolete
  • SwitchCircuit: SPST - NO
  • Multiplexer/DemultiplexerCircuit: 1:1
  • NumberofCircuits: 4
  • On-StateResistance(Max): 35Ohm
  • Channel-to-ChannelMatching(ΔRon): -
  • Voltage-SupplySingle(V+): 12V
  • Voltage-SupplyDual(V±): ±15V
  • SwitchTime(TonToff)(Max): 175ns, 145ns
  • -3dbBandwidth: -
  • ChargeInjection: 5pC
  • ChannelCapacitance(CS(off)CD(off)): 9pF, 9pF
  • Current-Leakage(IS(off))(Max): 250pA
  • Crosstalk: -85dB @ 1MHz
  • OperatingTemperature: -40°C ~ 85°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 16-SOIC (0.154, 3.90mm Width)
  • ADG412BR Analog Devices (ADI), PRECISION QUAD SPST SWITCH, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG412BR, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
