ADG413BNZ Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-DIP (0.300, 7.62mm)
- Description: IC SWITCH QUAD SPST 16DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG413BNZ Specifications:
- MfrPart.: ADG413BNZ
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: IC SWITCH QUAD SPST 16DIP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Active
- SwitchCircuit: SPST - NO/NC
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 35Ohm
- Channel-to-ChannelMatching(ΔRon): -
- Voltage-SupplySingle(V+): 12V
- Voltage-SupplyDual(V±): ±15V
- SwitchTime(TonToff)(Max): 175ns, 145ns
- -3dbBandwidth: -
- ChargeInjection: 5pC
- ChannelCapacitance(CS(off)CD(off)): 9pF, 9pF
- Current-Leakage(IS(off))(Max): 250pA
- Crosstalk: -85dB @ 1MHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Through Hole
- Package/Case: 16-DIP (0.300, 7.62mm)
- ADG413BNZ Analog Devices (ADI), IC SWITCH QUAD SPST 16DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG413BNZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
