ADG417BN Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 8-DIP (0.300, 7.62mm)
- Description: PRECISION SPST SWITCH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG417BN Specifications:
- MfrPart.: ADG417BN
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: PRECISION SPST SWITCH
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPST - NO
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 1
- On-StateResistance(Max): 35Ohm
- Channel-to-ChannelMatching(ΔRon): -
- Voltage-SupplySingle(V+): 10.8V ~ 13.2V, ±13.5V ~ 16.5V
- Voltage-SupplyDual(V±): 10.8V ~ 13.2V, ±13.5V ~ 16.5V
- SwitchTime(TonToff)(Max): 160ns, 100ns
- -3dbBandwidth: -
- ChargeInjection: 7pC
- ChannelCapacitance(CS(off)CD(off)): 6pF, 6pF
- Current-Leakage(IS(off))(Max): 250pA
- Crosstalk: -
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Through Hole
- Package/Case: 8-DIP (0.300, 7.62mm)
- ADG417BN Analog Devices (ADI), PRECISION SPST SWITCH, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG417BN, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
