ADG431BN ADI QUAD SPST SWITCH
ADG431BN Images
ADG431BN Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-DIP (0.300, 7.62mm)
  • Description: QUAD SPST SWITCH
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADG431BN Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADG431BN Specifications:
  • MfrPart.: ADG431BN
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: QUAD SPST SWITCH
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • SwitchCircuit: SPST - NC
  • Multiplexer/DemultiplexerCircuit: 1:1
  • NumberofCircuits: 4
  • On-StateResistance(Max): 24Ohm
  • Channel-to-ChannelMatching(ΔRon): 1.2Ohm
  • Voltage-SupplySingle(V+): 12V
  • Voltage-SupplyDual(V±): ±15V
  • SwitchTime(TonToff)(Max): 90ns, 60ns
  • -3dbBandwidth: -
  • ChargeInjection: 5pC
  • ChannelCapacitance(CS(off)CD(off)): 9pF, 9pF
  • Current-Leakage(IS(off))(Max): 250pA
  • Crosstalk: -85dB @ 1MHz
  • OperatingTemperature: -40°C ~ 85°C (TA)
  • MountingType: Through Hole
  • Package/Case: 16-DIP (0.300, 7.62mm)
  • ADG431BN Analog Devices (ADI), QUAD SPST SWITCH, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG431BN, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
