ADG438FBNZ ADI SINGLE-ENDED MULTIPLEXER, 1 FUNC
ADG438FBNZ Images
ADG438FBNZ Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-DIP (0.300, 7.62mm)
  • Description: SINGLE-ENDED MULTIPLEXER, 1 FUNC
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADG438FBNZ Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADG438FBNZ Specifications:
  • MfrPart.: ADG438FBNZ
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: SINGLE-ENDED MULTIPLEXER, 1 FUNC
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Bulk
  • Series: -
  • PartStatus: Obsolete
  • SwitchCircuit: -
  • Multiplexer/DemultiplexerCircuit: 8:1
  • NumberofCircuits: 1
  • On-StateResistance(Max): 270Ohm (Typ)
  • Channel-to-ChannelMatching(ΔRon): 8.1Ohm
  • Voltage-SupplySingle(V+): ±16.5V
  • Voltage-SupplyDual(V±): ±16.5V
  • SwitchTime(TonToff)(Max): 230ns, 130ns
  • -3dbBandwidth: -
  • ChargeInjection: 15pC
  • ChannelCapacitance(CS(off)CD(off)): 3pF, 22pF
  • Current-Leakage(IS(off))(Max): 500pA
  • Crosstalk: -93dB @ 100kHz
  • OperatingTemperature: -40°C ~ 125°C
  • MountingType: Through Hole
  • Package/Case: 16-DIP (0.300, 7.62mm)
  • ADG438FBNZ Analog Devices (ADI), SINGLE-ENDED MULTIPLEXER, 1 FUNC, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG438FBNZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
