ADG452BN ADI QUAD SPST SWITCH
ADG452BN Images
ADG452BN Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-DIP (0.300, 7.62mm)
  • Description: QUAD SPST SWITCH
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADG452BN Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADG452BN Specifications:
  • MfrPart.: ADG452BN
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: QUAD SPST SWITCH
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • SwitchCircuit: SPST - NO
  • Multiplexer/DemultiplexerCircuit: 1:1
  • NumberofCircuits: 4
  • On-StateResistance(Max): 5Ohm
  • Channel-to-ChannelMatching(ΔRon): 100mOhm
  • Voltage-SupplySingle(V+): 12V
  • Voltage-SupplyDual(V±): ±4.5V ~ 20V
  • SwitchTime(TonToff)(Max): 180ns, 140ns
  • -3dbBandwidth: -
  • ChargeInjection: 20pC
  • ChannelCapacitance(CS(off)CD(off)): 37pF, 37pF
  • Current-Leakage(IS(off))(Max): 500pA
  • Crosstalk: -90dB @ 1MHz
  • OperatingTemperature: -40°C ~ 85°C (TA)
  • MountingType: Through Hole
  • Package/Case: 16-DIP (0.300, 7.62mm)
  • ADG452BN Analog Devices (ADI), QUAD SPST SWITCH, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG452BN, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
