ADG509FBRUZ Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-TSSOP (0.173, 4.40mm Width)
- Description: IC MULTIPLEXER DUAL 4X1 16TSSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG509FBRUZ Specifications:
- MfrPart.: ADG509FBRUZ
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: IC MULTIPLEXER DUAL 4X1 16TSSOP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Active
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 270Ohm (Typ)
- Channel-to-ChannelMatching(ΔRon): 8.1Ohm
- Voltage-SupplySingle(V+): 15V
- Voltage-SupplyDual(V±): ±15V
- SwitchTime(TonToff)(Max): 230ns, 130ns
- -3dbBandwidth: -
- ChargeInjection: 15pC
- ChannelCapacitance(CS(off)CD(off)): 3pF, 12pF
- Current-Leakage(IS(off))(Max): 1nA
- Crosstalk: -
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-TSSOP (0.173, 4.40mm Width)
- ADG509FBRUZ Analog Devices (ADI), IC MULTIPLEXER DUAL 4X1 16TSSOP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG509FBRUZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
