ADG5209FBCPZ-RL7 ADI IC SWITCH SP4T DUAL 16LFCSP
ADG5209FBCPZ-RL7 Images
ADG5209FBCPZ-RL7 Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-WQFN Exposed Pad, CSP
  • Description: IC SWITCH SP4T DUAL 16LFCSP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADG5209FBCPZ-RL7 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADG5209FBCPZ-RL7 Specifications:
  • MfrPart.: ADG5209FBCPZ-RL7
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: IC SWITCH SP4T DUAL 16LFCSP
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • PartStatus: Active
  • SwitchCircuit: SP4T
  • Multiplexer/DemultiplexerCircuit: 4:1
  • NumberofCircuits: 2
  • On-StateResistance(Max): 160Ohm
  • Channel-to-ChannelMatching(ΔRon): 3.5Ohm
  • Voltage-SupplySingle(V+): 9V ~ 40V
  • Voltage-SupplyDual(V±): ±9V ~ 22V
  • SwitchTime(TonToff)(Max): 140ns, 185ns
  • -3dbBandwidth: 130MHz
  • ChargeInjection: 0.4pC
  • ChannelCapacitance(CS(off)CD(off)): 4pF, 8pF
  • Current-Leakage(IS(off))(Max): 1nA
  • Crosstalk: -
  • OperatingTemperature: -40°C ~ 125°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 16-WQFN Exposed Pad, CSP
  • ADG5209FBCPZ-RL7 Analog Devices (ADI), IC SWITCH SP4T DUAL 16LFCSP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG5209FBCPZ-RL7, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
