ADG5249FBRUZ ADI IC MULTIPLEXER 4X1 20TSSOP
ADG5249FBRUZ Images
ADG5249FBRUZ Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 20-TSSOP (0.173, 4.40mm Width)
  • Description: IC MULTIPLEXER 4X1 20TSSOP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADG5249FBRUZ Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADG5249FBRUZ Specifications:
  • MfrPart.: ADG5249FBRUZ
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: IC MULTIPLEXER 4X1 20TSSOP
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • SwitchCircuit: SP4T
  • Multiplexer/DemultiplexerCircuit: 4:1
  • NumberofCircuits: 2
  • On-StateResistance(Max): 335Ohm
  • Channel-to-ChannelMatching(ΔRon): 3Ohm
  • Voltage-SupplySingle(V+): 8V ~ 44V
  • Voltage-SupplyDual(V±): ±5V ~ 22V
  • SwitchTime(TonToff)(Max): 245ns, 135ns
  • -3dbBandwidth: 320MHz
  • ChargeInjection: -1.2pC
  • ChannelCapacitance(CS(off)CD(off)): 4pF, 7pF
  • Current-Leakage(IS(off))(Max): 1nA
  • Crosstalk: -75dB @ 1MHz
  • OperatingTemperature: -40°C ~ 125°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 20-TSSOP (0.173, 4.40mm Width)
  • ADG5249FBRUZ Analog Devices (ADI), IC MULTIPLEXER 4X1 20TSSOP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG5249FBRUZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
