ADG5409BCPZ Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-WQFN Exposed Pad, CSP
- Description: IC MULTIPLEXER 2 X 4:1 16LFCSP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG5409BCPZ Specifications:
- MfrPart.: ADG5409BCPZ-REEL7
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: IC MULTIPLEXER 2 X 4:1 16LFCSP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 14Ohm
- Channel-to-ChannelMatching(ΔRon): 300mOhm
- Voltage-SupplySingle(V+): 9V ~ 40V
- Voltage-SupplyDual(V±): ±9V ~ 22V
- SwitchTime(TonToff)(Max): 165ns, 153ns
- -3dbBandwidth: 88MHz
- ChargeInjection: 155pC
- ChannelCapacitance(CS(off)CD(off)): 17pF, 48pF
- Current-Leakage(IS(off))(Max): 250pA
- Crosstalk: -60dB @ 1MHz
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-WQFN Exposed Pad, CSP
- ADG5409BCPZ Analog Devices (ADI), IC MULTIPLEXER 2 X 4:1 16LFCSP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG5409BCPZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
