ADG5421FBCPZ-RL7 Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 10-WFDFN Exposed Pad, CSP
- Description: 60V OV PROTECTED, HV SPSTX2 SWIT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG5421FBCPZ-RL7 Specifications:
- MfrPart.: ADG5421FBCPZ-RL7
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: 60V OV PROTECTED, HV SPSTX2 SWIT
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- SwitchCircuit: SPST - NC
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 2
- On-StateResistance(Max): 14Ohm
- Channel-to-ChannelMatching(ΔRon): 20mOhm
- Voltage-SupplySingle(V+): 8V ~ 44V, ±5V ~ 22V
- Voltage-SupplyDual(V±): 8V ~ 44V, ±5V ~ 22V
- SwitchTime(TonToff)(Max): 15.9µs, 160ns
- -3dbBandwidth: 630MHz
- ChargeInjection: -150pC
- ChannelCapacitance(CS(off)CD(off)): 6pF, 5pF
- Current-Leakage(IS(off))(Max): 200pA
- Crosstalk: -78dB @ 1MHz
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 10-WFDFN Exposed Pad, CSP
- ADG5421FBCPZ-RL7 Analog Devices (ADI), 60V OV PROTECTED, HV SPSTX2 SWIT, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG5421FBCPZ-RL7, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
