ADG5436BRUZ ADI IC SWITCH DUAL SPDT 16TSSOP
ADG5436BRUZ Images
ADG5436BRUZ Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-TSSOP (0.173, 4.40mm Width)
  • Description: IC SWITCH DUAL SPDT 16TSSOP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADG5436BRUZ Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADG5436BRUZ Specifications:
  • MfrPart.: ADG5436BRUZ
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: IC SWITCH DUAL SPDT 16TSSOP
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • SwitchCircuit: SPDT
  • Multiplexer/DemultiplexerCircuit: 2:1
  • NumberofCircuits: 2
  • On-StateResistance(Max): 10Ohm
  • Channel-to-ChannelMatching(ΔRon): 350mOhm
  • Voltage-SupplySingle(V+): 9V ~ 40V
  • Voltage-SupplyDual(V±): ±9V ~ 22V
  • SwitchTime(TonToff)(Max): 213ns, 152ns
  • -3dbBandwidth: 100MHz
  • ChargeInjection: 250pC
  • ChannelCapacitance(CS(off)CD(off)): 18pF, 63pF
  • Current-Leakage(IS(off))(Max): 250pA
  • Crosstalk: -58dB @ 1MHz
  • OperatingTemperature: -40°C ~ 125°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 16-TSSOP (0.173, 4.40mm Width)
  • ADG5436BRUZ Analog Devices (ADI), IC SWITCH DUAL SPDT 16TSSOP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG5436BRUZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
