ADG5436FBCPZ-RL7 Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-WQFN Exposed Pad, CSP
- Description: IC SWITCH DUAL SPDT 16LFCSP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG5436FBCPZ-RL7 Specifications:
- MfrPart.: ADG5436FBCPZ-RL7
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: IC SWITCH DUAL SPDT 16LFCSP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- SwitchCircuit: SPDT
- Multiplexer/DemultiplexerCircuit: 2:1
- NumberofCircuits: 2
- On-StateResistance(Max): 11.5Ohm
- Channel-to-ChannelMatching(ΔRon): 150mOhm
- Voltage-SupplySingle(V+): 8V ~ 44V
- Voltage-SupplyDual(V±): ±5V ~ 22V
- SwitchTime(TonToff)(Max): 535ns, 205ns
- -3dbBandwidth: 171MHz
- ChargeInjection: -737pC
- ChannelCapacitance(CS(off)CD(off)): 11pF, 23pF
- Current-Leakage(IS(off))(Max): 500pA
- Crosstalk: -73dB @ 1MHz
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-WQFN Exposed Pad, CSP
- ADG5436FBCPZ-RL7 Analog Devices (ADI), IC SWITCH DUAL SPDT 16LFCSP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG5436FBCPZ-RL7, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
