ADG601BRT Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: SOT-23-6
- Description: SPST, 1 CHANNEL, CMOS
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG601BRT Specifications:
- MfrPart.: ADG601BRT-REEL7
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: SPST, 1 CHANNEL, CMOS
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPST - NO
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 1
- On-StateResistance(Max): 2.5Ohm
- Channel-to-ChannelMatching(ΔRon): -
- Voltage-SupplySingle(V+): 2.7V ~ 5.5V, ±2.7V ~ 5.5V
- Voltage-SupplyDual(V±): 2.7V ~ 5.5V, ±2.7V ~ 5.5V
- SwitchTime(TonToff)(Max): 120ns, 75ns
- -3dbBandwidth: 180MHz
- ChargeInjection: 250pC
- ChannelCapacitance(CS(off)CD(off)): 50pF, 50pF
- Current-Leakage(IS(off))(Max): 250pA
- Crosstalk: -
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Surface Mount
- Package/Case: SOT-23-6
- ADG601BRT Analog Devices (ADI), SPST, 1 CHANNEL, CMOS, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG601BRT, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
