ADG659YCPZ ADI IC MULTIPLEXER 4:1 16LFCSP
ADG659YCPZ Images
ADG659YCPZ Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-VQFN Exposed Pad, CSP
  • Description: IC MULTIPLEXER 4:1 16LFCSP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADG659YCPZ Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADG659YCPZ Specifications:
  • MfrPart.: ADG659YCPZ-REEL7
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: IC MULTIPLEXER 4:1 16LFCSP
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • PartStatus: Active
  • SwitchCircuit: SP4T
  • Multiplexer/DemultiplexerCircuit: 4:1
  • NumberofCircuits: 2
  • On-StateResistance(Max): 75Ohm
  • Channel-to-ChannelMatching(ΔRon): 1.3Ohm
  • Voltage-SupplySingle(V+): 2V ~ 12V
  • Voltage-SupplyDual(V±): ±2V ~ 6V
  • SwitchTime(TonToff)(Max): 115ns, 45ns
  • -3dbBandwidth: 400MHz
  • ChargeInjection: 2pC
  • ChannelCapacitance(CS(off)CD(off)): 4pF, 12pF
  • Current-Leakage(IS(off))(Max): 200pA
  • Crosstalk: -90dB @ 1MHz
  • OperatingTemperature: -40°C ~ 85°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 16-VQFN Exposed Pad, CSP
  • ADG659YCPZ Analog Devices (ADI), IC MULTIPLEXER 4:1 16LFCSP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG659YCPZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
