ADG701LBRT Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: SOT-23-6
- Description: SPST, 1 CHANNEL, CMOS
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG701LBRT Specifications:
- MfrPart.: ADG701LBRT-REEL7
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: SPST, 1 CHANNEL, CMOS
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPST - NO
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 1
- On-StateResistance(Max): 3Ohm
- Channel-to-ChannelMatching(ΔRon): -
- Voltage-SupplySingle(V+): 1.8V ~ 5V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 12ns, 8ns (Typ)
- -3dbBandwidth: 200MHz
- ChargeInjection: 5pC
- ChannelCapacitance(CS(off)CD(off)): 17pF, 17pF
- Current-Leakage(IS(off))(Max): 250pA
- Crosstalk: -
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: SOT-23-6
- ADG701LBRT Analog Devices (ADI), SPST, 1 CHANNEL, CMOS, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG701LBRT, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
