ADG709BRU ADI DIFFERENTIAL MUX,4 CHANNEL
ADG709BRU Images
ADG709BRU Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-TSSOP (0.173, 4.40mm Width)
  • Description: DIFFERENTIAL MUX,4 CHANNEL
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADG709BRU Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADG709BRU Specifications:
  • MfrPart.: ADG709BRU
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: DIFFERENTIAL MUX,4 CHANNEL
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • SwitchCircuit: SP4T
  • Multiplexer/DemultiplexerCircuit: 4:1
  • NumberofCircuits: 2
  • On-StateResistance(Max): 4.5Ohm
  • Channel-to-ChannelMatching(ΔRon): 400mOhm
  • Voltage-SupplySingle(V+): 1.8V ~ 5.5V
  • Voltage-SupplyDual(V±): ±2.5V
  • SwitchTime(TonToff)(Max): 14ns, 8ns (Typ)
  • -3dbBandwidth: 55MHz
  • ChargeInjection: 3pC
  • ChannelCapacitance(CS(off)CD(off)): 13pF, 42pF
  • Current-Leakage(IS(off))(Max): 10pA (Typ)
  • Crosstalk: -80dB @ 1MHz
  • OperatingTemperature: -40°C ~ 125°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 16-TSSOP (0.173, 4.40mm Width)
  • ADG709BRU Analog Devices (ADI), DIFFERENTIAL MUX,4 CHANNEL, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG709BRU, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
