ADG713BR Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-SOIC (0.154, 3.90mm Width)
- Description: QUAD SPST SWITCH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG713BR Specifications:
- MfrPart.: ADG713BR-REEL7
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: QUAD SPST SWITCH
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPST - NO/NC
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 4Ohm
- Channel-to-ChannelMatching(ΔRon): 50mOhm
- Voltage-SupplySingle(V+): 1.8V ~ 5.5V
- Voltage-SupplyDual(V±): 1.8V ~ 5.5V
- SwitchTime(TonToff)(Max): 11ns (Typ), 6ns (Typ)
- -3dbBandwidth: 200MHz
- ChargeInjection: 3pC
- ChannelCapacitance(CS(off)CD(off)): 10pF, 10pF
- Current-Leakage(IS(off))(Max): 100pA
- Crosstalk: -90dB @ 10MHz
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.154, 3.90mm Width)
- ADG713BR Analog Devices (ADI), QUAD SPST SWITCH, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG713BR, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
