ADG759BCP Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 20-WFQFN Exposed Pad, CSP
- Description: DIFFERENTIAL MUX,4 CHANNEL
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG759BCP Specifications:
- MfrPart.: ADG759BCP-REEL
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: DIFFERENTIAL MUX,4 CHANNEL
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 4.5Ohm
- Channel-to-ChannelMatching(ΔRon): 750mOhm
- Voltage-SupplySingle(V+): 1.8V ~ 5.5V, ±2.5V
- Voltage-SupplyDual(V±): 1.8V ~ 5.5V, ±2.5V
- SwitchTime(TonToff)(Max): 14ns (Typ), 8ns (Typ)
- -3dbBandwidth: 55MHz
- ChargeInjection: 3pC
- ChannelCapacitance(CS(off)CD(off)): 13pF, 42pF
- Current-Leakage(IS(off))(Max): 100pA
- Crosstalk: -80dB @ 1MHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 20-WFQFN Exposed Pad, CSP
- ADG759BCP Analog Devices (ADI), DIFFERENTIAL MUX,4 CHANNEL, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG759BCP, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
