ADG791GBCPZ Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 24-VFQFN Exposed Pad, CSP
- Description: I2C QUAD 2:1 MUX
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG791GBCPZ Specifications:
- MfrPart.: ADG791GBCPZ-REEL
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: I2C QUAD 2:1 MUX
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPDT
- Multiplexer/DemultiplexerCircuit: 2:1
- NumberofCircuits: 4
- On-StateResistance(Max): 4Ohm
- Channel-to-ChannelMatching(ΔRon): 150mOhm
- Voltage-SupplySingle(V+): 3V, 5V
- Voltage-SupplyDual(V±): 3V, 5V
- SwitchTime(TonToff)(Max): 250ns, 240ns
- -3dbBandwidth: 325MHz
- ChargeInjection: 5pC
- ChannelCapacitance(CS(off)CD(off)): 10pF, 13pF
- Current-Leakage(IS(off))(Max): 250pA (Typ)
- Crosstalk: -70dB @ 10MHz
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Surface Mount
- Package/Case: 24-VFQFN Exposed Pad, CSP
- ADG791GBCPZ Analog Devices (ADI), I2C QUAD 2:1 MUX, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG791GBCPZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
