ADG794BRQZ Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-SSOP (0.154, 3.90mm Width)
- Description: IC MUX/DEMUX QUAD 2X1 16QSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG794BRQZ Specifications:
- MfrPart.: ADG794BRQZ-REEL7
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: IC MUX/DEMUX QUAD 2X1 16QSOP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- SwitchCircuit: SPDT
- Multiplexer/DemultiplexerCircuit: 2:1
- NumberofCircuits: 4
- On-StateResistance(Max): 7Ohm
- Channel-to-ChannelMatching(ΔRon): 400mOhm
- Voltage-SupplySingle(V+): 3.3V, 5V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 7ns, 5ns (Typ)
- -3dbBandwidth: 300MHz
- ChargeInjection: 7.5pC
- ChannelCapacitance(CS(off)CD(off)): 8pF, 14pF
- Current-Leakage(IS(off))(Max): 1pA (Typ)
- Crosstalk: -70dB @ 10MHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-SSOP (0.154, 3.90mm Width)
- ADG794BRQZ Analog Devices (ADI), IC MUX/DEMUX QUAD 2X1 16QSOP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG794BRQZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
