ADG820BRTZ ADI 2:1 MUX/SPDT SWITCH
ADG820BRTZ Images
ADG820BRTZ Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: SOT-23-6
  • Description: 2:1 MUX/SPDT SWITCH
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADG820BRTZ Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADG820BRTZ Specifications:
  • MfrPart.: ADG820BRTZ-REEL7
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: 2:1 MUX/SPDT SWITCH
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Bulk
  • Series: -
  • PartStatus: Obsolete
  • SwitchCircuit: SPDT
  • Multiplexer/DemultiplexerCircuit: 2:1
  • NumberofCircuits: 1
  • On-StateResistance(Max): 600mOhm
  • Channel-to-ChannelMatching(ΔRon): 60mOhm
  • Voltage-SupplySingle(V+): 1.8V ~ 5.5V
  • Voltage-SupplyDual(V±): 1.8V ~ 5.5V
  • SwitchTime(TonToff)(Max): 45ns, 16ns
  • -3dbBandwidth: 17MHz
  • ChargeInjection: 20pC
  • ChannelCapacitance(CS(off)CD(off)): 80pF
  • Current-Leakage(IS(off))(Max): 250pA
  • Crosstalk: -72dB @ 100kHz
  • OperatingTemperature: -40°C ~ 125°C (TA)
  • MountingType: Surface Mount
  • Package/Case: SOT-23-6
  • ADG820BRTZ Analog Devices (ADI), 2:1 MUX/SPDT SWITCH, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG820BRTZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
