ADG836LYRMZ ADI IC SWITCH DUAL SPDT 10MSOP
ADG836LYRMZ Images
ADG836LYRMZ Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
  • Description: IC SWITCH DUAL SPDT 10MSOP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADG836LYRMZ Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADG836LYRMZ Specifications:
  • MfrPart.: ADG836LYRMZ
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: IC SWITCH DUAL SPDT 10MSOP
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • SwitchCircuit: SPDT
  • Multiplexer/DemultiplexerCircuit: 2:1
  • NumberofCircuits: 2
  • On-StateResistance(Max): 650mOhm
  • Channel-to-ChannelMatching(ΔRon): 40mOhm
  • Voltage-SupplySingle(V+): 1.65V ~ 3.6V
  • Voltage-SupplyDual(V±): -
  • SwitchTime(TonToff)(Max): 26ns, 7ns
  • -3dbBandwidth: 57MHz
  • ChargeInjection: 40pC
  • ChannelCapacitance(CS(off)CD(off)): 25pF
  • Current-Leakage(IS(off))(Max): 1nA
  • Crosstalk: -90dB @ 100kHz
  • OperatingTemperature: -40°C ~ 125°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
  • ADG836LYRMZ Analog Devices (ADI), IC SWITCH DUAL SPDT 10MSOP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG836LYRMZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
