ADG836YCP Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 12-VFQFN Exposed Pad, CSP
- Description: DUAL SPDT/2:1 MUX
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG836YCP Specifications:
- MfrPart.: ADG836YCP-REEL
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: DUAL SPDT/2:1 MUX
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPDT
- Multiplexer/DemultiplexerCircuit: 2:1
- NumberofCircuits: 2
- On-StateResistance(Max): 650mOhm
- Channel-to-ChannelMatching(ΔRon): 40mOhm
- Voltage-SupplySingle(V+): 1.65V ~ 3.6V
- Voltage-SupplyDual(V±): 1.65V ~ 3.6V
- SwitchTime(TonToff)(Max): 26ns, 7ns
- -3dbBandwidth: 57MHz
- ChargeInjection: 40pC
- ChannelCapacitance(CS(off)CD(off)): 25pF
- Current-Leakage(IS(off))(Max): 200pA (Typ)
- Crosstalk: -90dB @ 100kHz
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 12-VFQFN Exposed Pad, CSP
- ADG836YCP Analog Devices (ADI), DUAL SPDT/2:1 MUX, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG836YCP, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
