ADGS1212BCPZ-RL7 Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 24-WFQFN Exposed Pad, CSP
- Description: IC SWITCH SPST QUAD 24-LFCSP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADGS1212BCPZ-RL7 Specifications:
- MfrPart.: ADGS1212BCPZ-RL7
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: IC SWITCH SPST QUAD 24-LFCSP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- SwitchCircuit: SPST - NO
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 260Ohm, 625Ohm
- Channel-to-ChannelMatching(ΔRon): 11Ohm, 27Ohm
- Voltage-SupplySingle(V+): 5V ~ 16.5V
- Voltage-SupplyDual(V±): ±4.5V ~ 16.5V
- SwitchTime(TonToff)(Max): 490ns, 225ns
- -3dbBandwidth: 1GHz
- ChargeInjection: 1pC
- ChannelCapacitance(CS(off)CD(off)): 1.4pF, 1.5pF
- Current-Leakage(IS(off))(Max): 1nA
- Crosstalk: -110dB @ 1MHz
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 24-WFQFN Exposed Pad, CSP
- ADGS1212BCPZ-RL7 Analog Devices (ADI), IC SWITCH SPST QUAD 24-LFCSP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADGS1212BCPZ-RL7, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
