ADM7171ACPZ-R7 Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear Package/Case: 8-WFDFN Exposed Pad, CSP
- Description: IC REG LINEAR POS ADJ 1A 8LFCSP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADM7171ACPZ-R7 Specifications:
- MfrPart.: ADM7171ACPZ-R7
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: IC REG LINEAR POS ADJ 1A 8LFCSP
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- OutputConfiguration: Positive
- OutputType: Adjustable
- NumberofRegulators: 1
- Voltage-Input(Max): 6.5V
- Voltage-Output(Min/Fixed): 1.2V
- Voltage-Output(Max): 6.365V
- VoltageDropout(Max): 0.135V @ 1A
- Current-Output: 1A
- Current-Quiescent(Iq): 2 mA
- Current-Supply(Max): 6.3 mA
- PSRR: 60db ~ 20dB (100kHz ~ 1MHz)
- ControlFeatures: Enable, Soft Start
- ProtectionFeatures: Over Current, Over Temperature
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 8-WFDFN Exposed Pad, CSP
- ADM7171ACPZ-R7 Analog Devices (ADI), IC REG LINEAR POS ADJ 1A 8LFCSP, Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
ADM7171ACPZ-R7, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
