ADN4654BRSZ-RL7 ADI DGT ISO 3750VRMS 2CH LVDS 20SSOP
ADN4654BRSZ-RL7 Images
ADN4654BRSZ-RL7 Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Isolators~Digital Isolators Package/Case: 20-SSOP (0.209, 5.30mm Width)
  • Description: DGT ISO 3750VRMS 2CH LVDS 20SSOP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADN4654BRSZ-RL7 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADN4654BRSZ-RL7 Specifications:
  • MfrPart.: ADN4654BRSZ-RL7
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: DGT ISO 3750VRMS 2CH LVDS 20SSOP
  • Product Category: Isolators~Digital Isolators
  • Package: Tape & Reel (TR)
  • Series: iCoupler®
  • PartStatus: Active
  • Technology: Magnetic Coupling
  • Type: LVDS
  • IsolatedPower: No
  • NumberofChannels: 2
  • Inputs-Side1/Side2: 2/0
  • ChannelType: Unidirectional
  • Voltage-Isolation: 3750Vrms
  • CommonModeTransientImmunity(Min): 25kV/µs
  • DataRate: 1.1Gbps
  • PropagationDelaytpLH/tpHL(Max): 4.5ns, 4.5ns
  • PulseWidthDistortion(Max): -
  • Rise/FallTime(Typ): 0.35ns, 0.35ns (Max)
  • Voltage-Supply: 2.375V ~ 2.625V
  • OperatingTemperature: -40°C ~ 125°C
  • MountingType: Surface Mount
  • Package/Case: 20-SSOP (0.209, 5.30mm Width)
  • ADN4654BRSZ-RL7 Analog Devices (ADI), DGT ISO 3750VRMS 2CH LVDS 20SSOP, Isolators~Digital Isolators
ADN4654BRSZ-RL7, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
