ADP2109ACBZ-1.0-R7 ADI 600MA, 3MHZ, STEP-DOWN CONVERTER
ADP2109ACBZ-1.0-R7 Images
ADP2109ACBZ-1.0-R7 Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Regulators Package/Case: 5-WFBGA, WLCSP
  • Description: 600MA, 3MHZ, STEP-DOWN CONVERTER
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADP2109ACBZ-1.0-R7 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADP2109ACBZ-1.0-R7 Specifications:
  • MfrPart.: ADP2109ACBZ-1.0-R7
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: 600MA, 3MHZ, STEP-DOWN CONVERTER
  • Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Regulators
  • Package: Bulk
  • Series: -
  • PartStatus: Obsolete
  • Function: Step-Down
  • OutputConfiguration: Positive
  • Topology: Buck
  • OutputType: Fixed
  • NumberofOutputs: 1
  • Voltage-Input(Min): 2.3V
  • Voltage-Input(Max): 5.5V
  • Voltage-Output(Min/Fixed): 1V
  • Voltage-Output(Max): -
  • Current-Output: 600mA
  • Frequency-Switching: 3MHz
  • SynchronousRectifier: Yes
  • OperatingTemperature: -40°C ~ 85°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 5-WFBGA, WLCSP
  • ADP2109ACBZ-1.0-R7 Analog Devices (ADI), 600MA, 3MHZ, STEP-DOWN CONVERTER, Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Regulators
ADP2109ACBZ-1.0-R7, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
