ADP2114ACPZ-R2 Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Regulators Package/Case: 32-WFQFN Exposed Pad, CSP
- Description: DUAL SWITCHING CONTROLLER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADP2114ACPZ-R2 Specifications:
- MfrPart.: ADP2114ACPZ-R2
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: DUAL SWITCHING CONTROLLER
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Regulators
- Package: Bulk
- Series: -
- PartStatus: Active
- Function: Step-Down
- OutputConfiguration: Positive
- Topology: Buck
- OutputType: Adjustable (Programmable)
- NumberofOutputs: 1 or 2
- Voltage-Input(Min): 2.75V
- Voltage-Input(Max): 5.5V
- Voltage-Output(Min/Fixed): 0.6V (0.8V, 1.2V, 1.5V, 1.8V, 2.5V, 3.3V)
- Voltage-Output(Max): 5.5V
- Current-Output: 4A, 2A
- Frequency-Switching: 300kHz, 600kHz, 1.2MHz
- SynchronousRectifier: Yes
- OperatingTemperature: -40°C ~ 125°C (TJ)
- MountingType: Surface Mount
- Package/Case: 32-WFQFN Exposed Pad, CSP
- ADP2114ACPZ-R2 Analog Devices (ADI), DUAL SWITCHING CONTROLLER, Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Regulators
ADP2114ACPZ-R2, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
