ADUM1100AR-RL7 ADI ADUM1100 - ICOUPLER DIGITAL ISOL
ADUM1100AR-RL7 Images
ADUM1100AR-RL7 Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Isolators~Digital Isolators Package/Case: 8-SOIC (0.154, 3.90mm Width)
  • Description: ADUM1100 - ICOUPLER DIGITAL ISOL
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADUM1100AR-RL7 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADUM1100AR-RL7 Specifications:
  • MfrPart.: ADUM1100AR-RL7
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: ADUM1100 - ICOUPLER DIGITAL ISOL
  • Product Category: Isolators~Digital Isolators
  • Package: Bulk
  • Series: iCoupler®
  • PartStatus: Active
  • Technology: Magnetic Coupling
  • Type: General Purpose
  • IsolatedPower: No
  • NumberofChannels: 1
  • Inputs-Side1/Side2: 1/0
  • ChannelType: Unidirectional
  • Voltage-Isolation: 2500Vrms
  • CommonModeTransientImmunity(Min): 25kV/µs
  • DataRate: 25Mbps
  • PropagationDelaytpLH/tpHL(Max): 18ns, 18ns
  • PulseWidthDistortion(Max): 2ns
  • Rise/FallTime(Typ): 3ns, 3ns
  • Voltage-Supply: 3V ~ 5.5V
  • OperatingTemperature: -40°C ~ 105°C
  • MountingType: Surface Mount
  • Package/Case: 8-SOIC (0.154, 3.90mm Width)
  • ADUM1100AR-RL7 Analog Devices (ADI), ADUM1100 - ICOUPLER DIGITAL ISOL, Isolators~Digital Isolators
ADUM1100AR-RL7, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
