ADUM1201WSRZ55 ADI DGTL ISO 2500VRMS 2CH GP 8SOIC
ADUM1201WSRZ55 Images
ADUM1201WSRZ55 Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Isolators~Digital Isolators Package/Case: 8-SOIC (0.154, 3.90mm Width)
  • Description: DGTL ISO 2500VRMS 2CH GP 8SOIC
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADUM1201WSRZ55 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADUM1201WSRZ55 Specifications:
  • MfrPart.: ADUM1201WSRZ55
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: DGTL ISO 2500VRMS 2CH GP 8SOIC
  • Product Category: Isolators~Digital Isolators
  • Package: Tube
  • Series: iCoupler®
  • PartStatus: Obsolete
  • Technology: Magnetic Coupling
  • Type: General Purpose
  • IsolatedPower: No
  • NumberofChannels: 2
  • Inputs-Side1/Side2: 1/1
  • ChannelType: Unidirectional
  • Voltage-Isolation: 2500Vrms
  • CommonModeTransientImmunity(Min): 25kV/µs
  • DataRate: 1Mbps
  • PropagationDelaytpLH/tpHL(Max): 150ns, 150ns
  • PulseWidthDistortion(Max): 40ns
  • Rise/FallTime(Typ): 10ns, 10ns
  • Voltage-Supply: 2.7V ~ 5.5V
  • OperatingTemperature: -40°C ~ 125°C
  • MountingType: Surface Mount
  • Package/Case: 8-SOIC (0.154, 3.90mm Width)
  • ADUM1201WSRZ55 Analog Devices (ADI), DGTL ISO 2500VRMS 2CH GP 8SOIC, Isolators~Digital Isolators
ADUM1201WSRZ55, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
