ADUM1300WTRWZ55 ADI DGTL ISO 2500VRMS 3CH GP 16SOIC
ADUM1300WTRWZ55 Images
ADUM1300WTRWZ55 Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Isolators~Digital Isolators Package/Case: 16-SOIC (0.295, 7.50mm Width)
  • Description: DGTL ISO 2500VRMS 3CH GP 16SOIC
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADUM1300WTRWZ55 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADUM1300WTRWZ55 Specifications:
  • MfrPart.: ADUM1300WTRWZ55
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: DGTL ISO 2500VRMS 3CH GP 16SOIC
  • Product Category: Isolators~Digital Isolators
  • Package: Tube
  • Series: Automotive
  • PartStatus: Obsolete
  • Technology: Magnetic Coupling
  • Type: General Purpose
  • IsolatedPower: No
  • NumberofChannels: 3
  • Inputs-Side1/Side2: 3/0
  • ChannelType: Unidirectional
  • Voltage-Isolation: 2500Vrms
  • CommonModeTransientImmunity(Min): 25kV/µs
  • DataRate: 10Mbps
  • PropagationDelaytpLH/tpHL(Max): 32ns, 32ns
  • PulseWidthDistortion(Max): 3ns
  • Rise/FallTime(Typ): 2.5ns, 2.5ns
  • Voltage-Supply: 3V ~ 5.5V
  • OperatingTemperature: -40°C ~ 125°C
  • MountingType: Surface Mount
  • Package/Case: 16-SOIC (0.295, 7.50mm Width)
  • ADUM1300WTRWZ55 Analog Devices (ADI), DGTL ISO 2500VRMS 3CH GP 16SOIC, Isolators~Digital Isolators
ADUM1300WTRWZ55, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
