ADUM1301WSRWZ55-RL Images
- Manufacturer: Analog Devices (ADI)
- Category: Isolators~Digital Isolators Package/Case: 16-SOIC (0.295, 7.50mm Width)
- Description: DGTL ISO 2500VRMS 3CH GP 16SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADUM1301WSRWZ55-RL Specifications:
- MfrPart.: ADUM1301WSRWZ55-RL
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: DGTL ISO 2500VRMS 3CH GP 16SOIC
- Product Category: Isolators~Digital Isolators
- Package: Tape & Reel (TR)
- Series: Automotive
- PartStatus: Obsolete
- Technology: Magnetic Coupling
- Type: General Purpose
- IsolatedPower: No
- NumberofChannels: 3
- Inputs-Side1/Side2: 2/1
- ChannelType: Unidirectional
- Voltage-Isolation: 2500Vrms
- CommonModeTransientImmunity(Min): 25kV/µs
- DataRate: 1Mbps
- PropagationDelaytpLH/tpHL(Max): 100ns, 100ns
- PulseWidthDistortion(Max): 40ns
- Rise/FallTime(Typ): 2.5ns, 2.5ns
- Voltage-Supply: 3V ~ 5.5V
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.295, 7.50mm Width)
- ADUM1301WSRWZ55-RL Analog Devices (ADI), DGTL ISO 2500VRMS 3CH GP 16SOIC, Isolators~Digital Isolators
ADUM1301WSRWZ55-RL, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
