ADUM1420BRWZ Images
- Manufacturer: Analog Devices (ADI)
- Category: Isolators~Isolators - Gate Drivers Package/Case: 28-SOIC (0.295, 7.50mm Width)
- Description: QUAD PRECISION GATE DRIVER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADUM1420BRWZ Specifications:
- MfrPart.: ADUM1420BRWZ
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: QUAD PRECISION GATE DRIVER
- Product Category: Isolators~Isolators - Gate Drivers
- Package: Tube
- Series: iCoupler®
- PartStatus: Obsolete
- Technology: Magnetic Coupling
- NumberofChannels: 4
- Voltage-Isolation: 1667Vrms
- CommonModeTransientImmunity(Min): 75kV/µs
- PropagationDelaytpLH/tpHL(Max): 128ns, 128ns
- PulseWidthDistortion(Max): 8ns
- Rise/FallTime(Typ): 25ns, 25ns (Max)
- Current-OutputHighLow: -
- Current-PeakOutput: 100mA
- Voltage-Forward(Vf)(Typ): -
- Current-DCForward(If)(Max): -
- Voltage-OutputSupply: 12V ~ 18V
- OperatingTemperature: -40°C ~ 105°C
- MountingType: Surface Mount
- Package/Case: 28-SOIC (0.295, 7.50mm Width)
- ADUM1420BRWZ Analog Devices (ADI), QUAD PRECISION GATE DRIVER, Isolators~Isolators - Gate Drivers
