ADUM3220BRZ Images
- Manufacturer: Analog Devices (ADI)
- Category: Isolators~Isolators - Gate Drivers Package/Case: 8-SOIC (0.154, 3.90mm Width)
- Description: DGTL ISO 2.5KV GATE DRIVER 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADUM3220BRZ Specifications:
- MfrPart.: ADUM3220BRZ
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: DGTL ISO 2.5KV GATE DRIVER 8SOIC
- Product Category: Isolators~Isolators - Gate Drivers
- Package: Tube
- Series: iCoupler®
- PartStatus: Active
- Technology: Magnetic Coupling
- NumberofChannels: 2
- Voltage-Isolation: 2500Vrms
- CommonModeTransientImmunity(Min): 25kV/µs
- PropagationDelaytpLH/tpHL(Max): 60ns, 60ns
- PulseWidthDistortion(Max): -
- Rise/FallTime(Typ): 20ns, 20ns
- Current-OutputHighLow: -
- Current-PeakOutput: 4A
- Voltage-Forward(Vf)(Typ): -
- Current-DCForward(If)(Max): -
- Voltage-OutputSupply: 7.6V ~ 18V
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.154, 3.90mm Width)
- ADUM3220BRZ Analog Devices (ADI), DGTL ISO 2.5KV GATE DRIVER 8SOIC, Isolators~Isolators - Gate Drivers
ADUM3220BRZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
