ADUM4224WARWZ-RL ADI DGTL ISO 5KV 2CH GATE DVR 16SOIC
ADUM4224WARWZ-RL Images
ADUM4224WARWZ-RL Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Isolators~Isolators - Gate Drivers Package/Case: 16-SOIC (0.295, 7.50mm Width)
  • Description: DGTL ISO 5KV 2CH GATE DVR 16SOIC
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADUM4224WARWZ-RL Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADUM4224WARWZ-RL Specifications:
  • MfrPart.: ADUM4224WARWZ-RL
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: DGTL ISO 5KV 2CH GATE DVR 16SOIC
  • Product Category: Isolators~Isolators - Gate Drivers
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: Automotive
  • PartStatus: Active
  • Technology: Magnetic Coupling
  • NumberofChannels: 2
  • Voltage-Isolation: 5000Vrms
  • CommonModeTransientImmunity(Min): 25kV/µs
  • PropagationDelaytpLH/tpHL(Max): 54ns, 54ns
  • PulseWidthDistortion(Max): -
  • Rise/FallTime(Typ): 12ns, 12ns
  • Current-OutputHighLow: -
  • Current-PeakOutput: 4A
  • Voltage-Forward(Vf)(Typ): -
  • Current-DCForward(If)(Max): -
  • Voltage-OutputSupply: 4.5V ~ 18V
  • OperatingTemperature: -40°C ~ 125°C
  • MountingType: Surface Mount
  • Package/Case: 16-SOIC (0.295, 7.50mm Width)
  • ADUM4224WARWZ-RL Analog Devices (ADI), DGTL ISO 5KV 2CH GATE DVR 16SOIC, Isolators~Isolators - Gate Drivers
ADUM4224WARWZ-RL, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
