HMC508LP5E Images
- Manufacturer: Analog Devices (ADI)
- Category: Crystals, Oscillators, Resonators~VCOs (Voltage Controlled Oscillators) Package/Case: 32-VFQFN Exposed Pad, CSP
- Description: VCO 3.875GHZ/7.75GHZ 2-13V 5X5MM
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HMC508LP5E Specifications:
- MfrPart.: HMC508LP5E
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: VCO 3.875GHZ/7.75GHZ 2-13V 5X5MM
- Product Category: Crystals, Oscillators, Resonators~VCOs (Voltage Controlled Oscillators)
- Package: Strip
- Series: HMC508
- PartStatus: Active
- FrequencyRange: 3.65 ~ 4.1GHz, 7.3 ~ 8.2GHz
- Frequency-Center: 3.875GHz, 7.75GHz
- Voltage-Supply: 5V
- TuningVoltage(VDC): 2 V ~ 13 V
- 2ndHarmonicTyp(dBc): 20
- IccMax: 280mA
- Pushing(MHz/V): 10
- Power(dBm): 14.5±2.5, 7±3
- PhaseNoiseTyp(dBc/Hz): -116
- OperatingTemperature: -40°C ~ 85°C
- Package/Case: 32-VFQFN Exposed Pad, CSP
- Size/Dimension: 0.197 L x 0.197 W (5.00mm x 5.00mm)
- HMC508LP5E Analog Devices (ADI), VCO 3.875GHZ/7.75GHZ 2-13V 5X5MM, Crystals, Oscillators, Resonators~VCOs (Voltage Controlled Oscillators)
HMC508LP5E, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
