HMC509LP5TR Images
- Manufacturer: Analog Devices (ADI)
- Category: Crystals, Oscillators, Resonators~VCOs (Voltage Controlled Oscillators) Package/Case: 32-VFQFN Exposed Pad, CSP
- Description: VCO WITH OUTPUT DIVIDER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HMC509LP5TR Specifications:
- MfrPart.: HMC509LP5TR
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: VCO WITH OUTPUT DIVIDER
- Product Category: Crystals, Oscillators, Resonators~VCOs (Voltage Controlled Oscillators)
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- FrequencyRange: 3.9 ~ 4.4GHz, 7.8 ~ 8.8GHz
- Frequency-Center: 4.15GHz, 8.3GHz
- Voltage-Supply: 5V
- TuningVoltage(VDC): 2 V ~ 13 V
- 2ndHarmonicTyp(dBc): 10
- IccMax: 270mA
- Pushing(MHz/V): 10
- Power(dBm): 7.5±2.5, 12.5±2.5
- PhaseNoiseTyp(dBc/Hz): -115
- OperatingTemperature: -40°C ~ 85°C
- Package/Case: 32-VFQFN Exposed Pad, CSP
- Size/Dimension: 0.197 L x 0.197 W (5.00mm x 5.00mm)
- HMC509LP5TR Analog Devices (ADI), VCO WITH OUTPUT DIVIDER, Crystals, Oscillators, Resonators~VCOs (Voltage Controlled Oscillators)
HMC509LP5TR, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
