LT1158CN Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 16-DIP (0.300, 7.62mm)
- Description: IC GATE DRVR HALF-BRIDGE 16DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
LT1158CN Specifications:
- MfrPart.: LT1158CN#PBF
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: IC GATE DRVR HALF-BRIDGE 16DIP
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tube
- Series: -
- PartStatus: Active
- DrivenConfiguration: Half-Bridge
- ChannelType: Synchronous
- NumberofDrivers: 2
- GateType: N-Channel MOSFET
- Voltage-Supply: 5V ~ 30V
- LogicVoltage-VILVIH: 0.8V, 2V
- Current-PeakOutput(SourceSink): 500mA, 500mA
- InputType: Inverting, Non-Inverting
- HighSideVoltage-Max(Bootstrap): 56 V
- Rise/FallTime(Typ): 130ns, 120ns
- OperatingTemperature: 0°C ~ 125°C (TJ)
- MountingType: Through Hole
- Package/Case: 16-DIP (0.300, 7.62mm)
- LT1158CN Analog Devices (ADI), IC GATE DRVR HALF-BRIDGE 16DIP, Integrated Circuits (ICs)~PMIC - Gate Drivers
LT1158CN, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
