LT3045EDD-1 ADI IC REG LINEAR 0V 500MA 12DFN
LT3045EDD-1 Images
LT3045EDD-1 Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear Package/Case: 12-WFDFN Exposed Pad
  • Description: IC REG LINEAR 0V 500MA 12DFN
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
LT3045EDD-1 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
LT3045EDD-1 Specifications:
  • MfrPart.: LT3045EDD-1#PBF
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: IC REG LINEAR 0V 500MA 12DFN
  • Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • OutputConfiguration: Positive
  • OutputType: Programmable
  • NumberofRegulators: 1
  • Voltage-Input(Max): 20V
  • Voltage-Output(Min/Fixed): 0V
  • Voltage-Output(Max): 15V
  • VoltageDropout(Max): 0.45V @ 500mA
  • Current-Output: 500mA
  • Current-Quiescent(Iq): 20 µA
  • Current-Supply(Max): 25 mA
  • PSRR: 117dB ~ 53dB (120Hz ~ 10MHz)
  • ControlFeatures: Enable, Power Good, Soft Start
  • ProtectionFeatures: Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
  • OperatingTemperature: -40°C ~ 125°C (TJ)
  • MountingType: Surface Mount
  • Package/Case: 12-WFDFN Exposed Pad
  • LT3045EDD-1 Analog Devices (ADI), IC REG LINEAR 0V 500MA 12DFN, Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
LT3045EDD-1, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
